GS108T Smart Switch Software Administration Manual
Managing System Settings 3-17
v1.0, May 2007
Port Configuration
A screen similar to that shown below is located near the bottom of the LLDP Configuration Switch
Settings screen.
.
The following information about LLDP configuration for a port is displayed:
Admin Status: The administratively desired status of the local LLDP agent.
Notification Enable: Indicates whether or not notifications from the agent are enabled.
MED Notification Enable: Indicates whether or not MED notifications from the agent are
enabled.
Optional TLVs Tx Enabled: Indicates which TLVs are enabled for transmission.
Figure 3-15
Table 3-1. Legends for Optional Enabled TLVs
Category Legend Meaning
Basic P Port Description
N System Name
D System Description
C System Capabilities
802.1 P Port Vlan ID
802.3 M MAC/PHY Configuration/Status
L Link aggregation
F Frame size
