NETGEAR ProSafe GS108 User Manual

GS108T Smart Switch Software Administration Manual
3-20 Managing System Settings
v1.0, May 2007
• Chassis ID SubType: Indicates the basis for the Chassis ID entity.
• Chassis ID: Identifier for the particular chassis in the System.
• System Name: Administratively assigned system name.
• System Description: Textual description of the network entity, including the full name and
version identification of the system's hardware type.
• System Capabilities: Identifies the primary functions of the system.
• Enabled Capabilities: Identifies which of the primary functions are enabled.
• MED Device Type: Indicates whether the device is a MED device.
• Management Address: The address associated with the LLDP agent that may be used to
reach higher layer entities to assist discovery by network management.
• Port: Local port number.
• Port ID SubType: The basis for the identifier that is listed in the Port ID field.
• Port ID: Identifier for the port from which LLDPDU was transmitted.
• Port Description: Indicates the port’s description.
The following LLDP local port information is displayed:
• Port ID SubType: The basis for the identifier that is listed in the Port ID field.
• Port ID: Identifier for the port from which LLDPDU was transmitted.
• PVID: Port VLAN ID.
Table 3-2. Management Address
Item Description
Address Sub
Type
Indicates type of address that is listed in the management address field.
Interface Sub
Type
Numbering method used for defining the interface number.
Interface Number Identifies specific address associated with the management address.
OID Type of hardware component or protocol entity associated with the given
management address.

NETGEAR ProSafe GS108 Specifications

General

MAC address table	8000 entries
Maximum data transfer rate	1 Gbit/s
Full duplex	Yes
Networking standards	IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Latency	20 μs
Dimensions (WxDxH)	235.5 x 100.8 x 27 mm
Power requirements	5 V @ 2.8 A DC
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet
Switch type	Unmanaged
Basic switching RJ-45 Ethernet ports quantity	8
Noise level	0 dB
Mean time between failures (MTBF)	91.500 h
Power consumption (typical)	14 W
Safety	UL (UL 1950), CUL, C-Tick
LED indicators	Link, Power
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	760 g
