GS108T Smart Switch Software Administration Manual
Managing System Settings 3-21
v1.0, May 2007
Table 3-3. 802.3 Set Details
Item Description
Auto Negotiation If auto-negotiation supported and enabled in both the systems, there should be
no speed difference.
Aggregator Status Ports through which LLDPDU is transmitted is aggregated or not.
Aggregator ID Port ID information for the aggregated port.
Maximum Frame
Size
Maximum size of a frame that can be transmitted.
Table 3-4. MED Set Details
Item Description
Capabilities LLDP-MED Capabilities are specific to LLDP-MED Devices, advertisement of this TLV by
Endpoints enables LLDP-MED capable Network Connectivity Devices to definitively
determine support of LLDP-MED by Endpoints they are connecting to.
Device Type A specific type of LLDP-MED Device, which may be either a Network Connectivity
Device or a specific Class of Endpoint Device.
Location
Format
Indicates the specific Location ID data format being delivered in the Location ID field.
Location ID Three Location ID data formats are defined.
• Coordinate-based LCI data format
• Civic Address LCI data format
• ECS ELIN data format
Power Type The Power Type field represents, whether LLDP-MED device transmitting the LLDPDU
is a Power Sourcing Entity (PSE) or Power Device (PD).
Power
Source
The Power Source field represents the power source being utilized by a PSE or PD
device.
Power
Priority
The Power Priority represents the priority of the PD type device to the power being
supplied by the PSE type device, or the power priority associated with the PSE type
device's port that is sourcing the power via MDI.

NETGEAR ProSafe GS108 Specifications

General

MAC address table	8000 entries
Maximum data transfer rate	1 Gbit/s
Full duplex	Yes
Networking standards	IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Latency	20 μs
Dimensions (WxDxH)	235.5 x 100.8 x 27 mm
Power requirements	5 V @ 2.8 A DC
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet
Switch type	Unmanaged
Basic switching RJ-45 Ethernet ports quantity	8
Noise level	0 dB
Mean time between failures (MTBF)	91.500 h
Power consumption (typical)	14 W
Safety	UL (UL 1950), CUL, C-Tick
LED indicators	Link, Power
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	760 g
