GS108T Smart Switch Software Administration Manual
Managing System Settings 3-23
v1.0, May 2007
.
The following LLDP remote information is displayed:
• Local Port: Port on which LLDPDU was received.
• Chassis ID SubType: Indicates the basis for the Chassis ID entity.
• Chassis ID: Identifier for the particular chassis in the System.
• Port ID SubType: The basis for the identifier that is listed in the Port ID field.
• Port ID: Identifier for the port from which LLDPDU was transmitted.
The following LLDP Remote Device Information is displayed:
• Port ID SubType: The basis for the identifier that is listed in the Port ID field.
• Port ID: Identifier for the port from which LLDPDU was transmitted.
• PVID: Port VLAN ID.
Figure 3-18
Table 3-5. 802.3 Set Details
Item Description
Auto Negotiation If auto-negotiation supported and enabled in both the systems, there should be
no speed difference.
Aggregator Status Ports through which LLDPDU is transmitted is aggregated or not.
