NETGEAR ProSafe GS108 User Manual

GS108T Smart Switch Software Administration Manual
3-30 Managing System Settings
v1.0, May 2007
.
b. Input the required information in the provided fields:
• Server IP: Input a valid IP Address for the remote server.
• UDP Port: Input the UDP port number to connect with the server.
• Facility: Input the type of facility. Select any one from the given eight facility types.
• Description: Give the description of server log (limit is 256 characters).
• Minimum Severity: Select the desired log level from the given eight log levels (e.g.,
Emergency, Alert, Critical, Error, Warning, Notice, Informational, or Debug).
c. Click Apply to add the server log.
Removing a server log from the Server Logs list
a. Check the server logs on the Server Logs page that need to be removed.
b. Click Apply to remove the server logs.
Figure 3-23

NETGEAR ProSafe GS108 Specifications

General

MAC address table	8000 entries
Maximum data transfer rate	1 Gbit/s
Full duplex	Yes
Networking standards	IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Latency	20 μs
Dimensions (WxDxH)	235.5 x 100.8 x 27 mm
Power requirements	5 V @ 2.8 A DC
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet
Switch type	Unmanaged
Basic switching RJ-45 Ethernet ports quantity	8
Noise level	0 dB
Mean time between failures (MTBF)	91.500 h
Power consumption (typical)	14 W
Safety	UL (UL 1950), CUL, C-Tick
LED indicators	Link, Power
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	760 g
