Communications 9
Pulse Laser Station NPL-302 Series Instruction Manual 191
The record formats shown above use the following codes:
Data example 91.3
20100,6606.165,1639.383,30.762,RKBSS
20104,1165611.6800,116401.4200,00032.8080
20105 5967.677 1102.343 34.353 MANHOLE
20106 4567.889 2340.665 33.444 PT1
20107 5967.677 1102.343 34.353
20109,4657.778,2335.667,,PT2
20111,4657.778,2335.667
20113 4657.778 2335.667
20115,,,34.353,MANHOLE
20117,,,33.444
Uploading Point Lists and Code Lists 9.2
Settings 92.1
To configure the transmission speed and other
settings, go to
MENU > Settings > Comm.
For more information, see Communications,
page 138.
Code Description Length
PT Point number Up to 16 digits
X Actual X coordinate Variable length
Y Actual Y coordinate Variable length
Z Actual Z coordinate Variable length
CD Feature code Up to 16 characters
