Applications 4
Pulse Laser Station NPL-302 Series Instruction Manual 95
Remote distance measurement 40.1
This function measures the horizontal distance, vertical distance, and slope distance
between two points.
rSD Slope distance between two points
rHD Horizontal distance between two points
rVD Vertical distance between two points
rV% Percentage of grade (rVD/rHD) × 100%
rGD Vertical grade (rHD/rVD) :1
rAZ Azimuth from first point to second point
1st sighting
point
rSD
2nd sighting point
rVD
rHD
Horizontal angle 0 direction
rHA
2nd sighting point
Station point
1st sighting
point
