Applications 4
Pulse Laser Station NPL-302 Series Instruction Manual 81
Stakeout 4.1
To display the Stakeout menu, press [S-O].
Specifying the stakeout point by angle and distance 41.1
1. To display the input screen for the distance and angle to the target, press [1] or
select
HA-HD in the Stakeout menu.
2. Enter the values and press [ENT].
HD Horizontal distance from station point to
stakeout point
dVD Vertical distance from station point to
stakeout point
HA Horizontal angle to stakeout point
R
IN
L
OUT
CUT
FiLL
IN OUT
Height
of target
R
L
FILL
CUT
