Preparation 2

Pulse Laser Station NPL-302 Series Instruction Manual 21

Preparing the Reflector Sheet 2.2

The reflector sheet can be used for measurements in Prism mode. Assemble the

reflector sheet as shown in Figure 2.3.

Figure 2.3 Reflector sheet assembly.

Reflector

sheet

Mini prism

adapter

Te les co p ic

prism pole

Prism pole

tripod type PPS
