Introduction 1
Pulse Laser Station NPL-302 Series Instruction Manual 5
Figure 1.2 Pulse Laser Station NPL-302 series – Face-2
Display and
face-2 keyboard
Horizontal axis
indication mark
Optical plummet
Data output/
external power
input connector
(Input voltage
7.2 – 11 V DC)
Leveling screw
Circular level
Objective
Leveling base
(LASER LIGHT IS
EMITTED FROM
THIS PART.)
The Laser Class Label
shown below is attached
(NPL-332 is not equipped
to the telescope
with face-2
display/keyboard
