Basic Card Printing Methods
11
2 Pull the card retainer, and load cards.
• Hold the card retainer lever with your fingers, and pull it right out.
• Load the card case with the printing side (front surface) to the left.
• When loading the cards, be sure to hold their edges, and never touch the front or rear printing sides.
3 Return the card retainer, and close the
cover.
• When returning the card retainer, be sure not to get
your fingers caught.
• Confirm that the card touches the upper roller of the
feeder.
4 Close the Top Cover.
The Card Case can be removed from the
printer. After loading the cards as in the
diagram at right, return the card retainer to
its original position, close the cover, and
reattach to the printer.
→See "How to Store Cards (Removing the Card
Case)" on page 53 for information on how to remove
the Card Case.
In order to prevent unauthorized printing, we recommend storing loaded Card Cases
separately from the printer.
→See "How to Store Cards (Removing the Card Case)" on page 53 for information on how to store the
Card Case.
Load cards in order starting from the right side of the card case. When printing begins
the right-most card is pulled into the printer.
The printing side of the card (front surface)
is on the left.
When using cards such as pre-printed
cards that have a specified orientation, load
the cards so that after printing, the printed
upper surface is at the rear of the cassette.
If cards are stuck to each other and do not
correctly feed, then lightly flex and separate
the cards before printing.
Roller
Rubber
Card Case
Card Retainer
To p
Bottom
To p
Bottom
Rear
Card Front Surface (Left Side)
To Next Page
