Basic Card Printing Methods
19
 Transfer Film Replacement
Use the following procedure when replacing the Transfer Film.
1 Remove the Transfer Film Cassette.
• Pull out the handle of the transfer film cassette with the
handle turned up.
Note
 When placing the Transfer Film down,
prevent contamination adhering by placing
it with the handle on the bottom.
2 Push down the pin on top of the
Transfer Film Cassette.
3 Remove the Transfer Film from the
Cassette.
• First, remove the spool spindle from the winding side
(black) holder, then remove the spool spindle from the
feed side (white) holder.
• When removing the spool spindle, pressing the spool
spindle downwards and tilting it to the side makes it
easy to remove.
a
b
Feed Side
Winding Side
