Basic Card Printing Methods
13
Loading Magnetic/IC Cards
The factory default for magnetic cards/IC cards is to be loaded as below.
→See "Loading Cards into the Card Case" on page 10 for the procedure on loading cards into the Card Case.
If using cards with JIS2 magnetic strips
• Load the JIS2 magnetic strips so that they are at the
left of the Card Case.
• Load the JIS2 magnetic strips so that they are at the
rear of the Card Case.
If using cards with ISO magnetic strips
• Load the ISO magnetic strips so that they are at the
right of the Card Case.
• Load the ISO magnetic strips so that they are at the
rear of the Card Case.
If using cards with IC terminals
• Load the IC terminals so that they are at the left of the
Card Case.
• Load the IC terminals so that they are at the rear of the
Card Case.
Printing on the magnetic strip/IC terminal cannot be guaranteed.
The surface with the JIS2 magnetic strip and the IC terminal is the printing side (front
surface).
In User Mode, [Set Face], you can set the orientation of loaded magnetic cards.
→See "Set the Orientation of Magnetic Cards/IC Cards to Load" on page 47 for information on how to load
magnetic cards.
Front
Surface
Card Case Rear
Card Case Front
Card Case Rear
Card Case Front
Rear
Surface
IC Terminal
Card Case Rear
Card Case Front
Front
Surface
To Next Page
