Calibration and Adjustment 5-1
5 Calibration and Adjustment
5.1 Overview
After initial installation or if any hardware changes have been made, certain dispensing system
components may need to be calibrated or adjusted. This section covers the following topics:
•
Focusing the Camera • Adjusting the Height Sensor Probe
•
Calibrating the Camera • Adjusting the Board Sensors
•
Service Station Height Adjustment • Initializing the Digital Gauges
•
Calibrating the Scale • Software Controlled Light Beacon
•
Z-head Counterbalance Force Adjustment
Refer to Section 6 - Operation for the following routine setup and adjustment procedures:
• Installing the Dispensing Valve
• Adjusting the Air Pressure
• Setting the Heaters
" NOTE Refer to the Fluidmove User Guide for information on Fluidmove programming and
fluid setup.
CAUTION! The procedures in this section should only be performed by a trained
service technician.
5.2 Safety First
Operation of your S-920 Dispensing System involves heat, air pressure, electrical power, mechanical
devices, and the use of hazardous materials. It is essential that every person servicing or operating the
dispensing system fully understands all hazards, risks, and safety precautions. Refer to Section 2 - Safety
for important safety information.
5.3 Record Keeping
The type of calibration or adjustment performed should be recorded in maintenance records for the
dispensing system along with names of technicians and other pertinent data.
5.4 Startup/Shutdown
Refer to Section 4 - Power Up and Testing for details on system and Fluidmove startup/shutdown
procedures.
