Installation 3-1
3 Installation
3.1 Overview
This section describes installation procedures for the Spectrum Series S-920 Dispensing System and
covers the following topics:
•
Uncrating and Placing the Dispensing System
•
Unpacking the Dispensing Chamber
•
Leveling the Dispensing System
•
Leveling the Scale
•
Setting Up the Service Station
•
Installing the Light Beacon
•
Installing the Laptop Computer
•
Installing the Camera
•
Anchoring the Dispensing System
3.2 Safety First
Operation of your S-920 Dispensing System involves heat, air pressure, electrical power, mechanical
devices, and the use of hazardous materials. It is essential that every person servicing or operating the
dispensing system fully understands all hazards, risks, and safety precautions. Refer to Section 2 - Safety
for additional information.
CAUTION! Installation procedures should only be performed by a trained service technician.
3.3 Facility Requirements
To ensure optimal performance and safety, it is necessary to install the dispensing system in a facility that
meets the requirements. If you have any questions about facility requirements, please contact Asymtek
Technical Support. See 10.2 Facility Requirements for detailed information.
3.4 Tools and Materials Needed
• 3 mm hex key • 1/2-inch wrench
• 9/16-inch wrench • Phillips Screwdriver (included in tool kit)
• Band Cutter • 1 ½-inch wrench (included in tool kit)
• Personal Protective Equipment • Diagonal-cut pliers
• Hammer • Forklift
• Flat Bar • Box Level
