Specifications 10-3
10.4 Stability Analysis
Table 10-4 Stability Analysis
Specifications
Center of Gravity
Single Station: 296.5 mm (11.67 in.)
Two Station: 800.7 mm (31.52 in.)
Three Station: 587.4 mm (23.12 in.)
Weight Distribution
(1)
Front Left
Front Right
Rear Right
Rear Left
92.0 kg (202.9 lbs)
93.9 kg (207.1 lbs)
94.2 kg (207.6 lbs)
91.8 kg (202.4 lbs)
Seismic Loading
Transverse Stability
Anchorage Force
Longitudinal Stability
Anchorage Force
Anchors Required
208.6 kg (460 lbs)
Anchors Required
64.4 kg (142 lbs)
Tilt Angle
(1)
Transverse Stability-CCW
Transverse Stability-CC
Longitudinal Stability-CCW
Longitudinal Stability-CC
17.1
16.8
30.8
31.5
(1)
User facing front end of the unit.
