3-4 Installation
10. Remove bag and plastic wrap from the machine.
" NOTE Location of packaging materials to be removed is indicated by the presence of
red warning tags.
11. Remove all shrink-wrap and other packing material from the perimeter of the dispensing
system.
12. Remove all perimeter packaging material from the dispensing area.
" NOTE Remove all shrink wrap and packing foam from the system prior to moving it to
a clean room. Also, remove the protective plastic film from the front door. If
necessary, clean the system thoroughly.
3.6 Unpacking the Dispensing Chamber
CAUTION! If the dispensing system is being installed in a clean room, remove all packaging
material and follow facility-recommended procedures before moving components
into the clean room.
To unpack the Dispensing Chamber:
1. Remove all tie wraps, tape, foam packing material, and warning tags from the following
areas:
• Dispensing Head
• Conveyor
• Service Station
" NOTE Location of packaging materials to be removed is indicated by the presence of
red warning tags. The amount, type, and arrangement of packaging materials will
depend on your system’s configuration.
2. Use a 3 mm hex key to loosen the setscrews on the X- and Y-axis Dispensing Head Stoppers.
See
Figure 3-3.
3. Remove the stoppers and retain them in a safe place.
