Installation 3-7
8. Loosen the strap covering the scale and remove the warning tag from the scale unit.
"NOTE Do not remove the strap. The strap may be needed when moving or shipping
machine.
9. Leave the scale uncovered until it has been leveled. See
3.8 Leveling the Scale.
Figure 3-7 S-920 Dispensing System Scale Stem
Scale Stem
