Troubleshooting 8-3
8.4.2 System Accuracy
Table 8-2 System Accuracy
Symptom Possible Cause Recovery Procedures
Loose camera lens
Refocus the camera. See 5.5 Focusing the
Camera.
Bad offset routines
Perform a Valve Offsets Routine. See 6.6
Establishing Machine Offsets.
Camera needs calibrated
Calibrate the camera. See 5.6 Calibrating the
Camera.
Cal Maps disabled
Enable Cal Maps. Contact a service
technician.
Bent needle
Replace the needle. Refer to the applicable
valve manual.
Inaccurate dispensing
Bad height sensor Contact Asymtek Technical Support.
Loose camera lens
Refocus the camera. See 5.5 Focusing the
Camera.
Fiducials not found
Corrupted vision file
Re-teach the vision targets or entire program
as necessary.
