3-6 Installation
5. Remove the tape covering the Service Station.
Figure 3-5 Removing the Service Station Packing Tape
6. Remove the front cover by first removing the two screws from the ends of the cover. See
Figure 3-6.
7. Lift the cover up and away from the machine.
CAUTION! The scale stem is extremely sensitive. Hitting or applying pressure to the scale
stem may damage the scale stem. See Figure 3-7.
Figure 3-6 Removing the Front Cover
