Verifying the RAID firmware 123
To upgrade or downgrade the RAID firmware
The firmware of the RAID card is upgraded through a flash process. The
flash process is initiated by running the RAID card firmware update utility
on the CallPilot CD-ROM.
WARNING
Nortel strongly recommends that you not perform low level
formatting. Performing low level formatting results in the drives
becoming unusable.
ATTENTION
Perform this procedure only if the firmware version is not the version identified in
this section.
Step Action
1
Insert the CallPilot tower 703t Image CD-ROM 1 of 3 into the server
CD-ROM drive.
2 Restart the server and observe the startup diagnostics.
3
When the processor diagnostics screen appears, press Esc.
Result: The following message appears at the bottom of the screen:
Entering boot selection menu ....
The system continues with the SCSI and RAID startup diagnostics,
and when done, a menu appears.
4 Choose ATAPI CD-ROM, and press Enter.
Result: The Startup menu appears.
5
Choose Utilities (for example, BIOS, Firmware, and so on), and then
press Enter.
Result: A menu appears.
6
Choose LSI Elite 1600 RAID card Firmware update, and press Enter.
7
Press Y for yes and then Enter to confirm that the 471gen.rom file
is detected.
8
Respond to the remaining prompts to proceed with the update.
Result: The update proceeds. When it is finished, you are informed
that the update completed successfully and you are asked to restart
the server.
9
Remove the CD-ROM from the CD-ROM drive.
