Chapter 10
RAID operations
In this chapter
"RAID overview" (page 121)
"Verifying the RAID firmware" (page 122)
"Configuring RAID using LSI Elite 1600 controller and Ctrl+M" (page 124)
"Verifying consistency on the drives" (page 128)
"RAID splitting" (page 129)
"Task summary for configuring RAID" (page 133)
"Task summary for RAID splitting" (page 134)
RAID overview
Redundant Array of Independent Disks (RAID) is a technology that can
combine two or more drives for fault tolerance and continued system
performance. The CallPilot RAID controller is a PCI RAID SCSI card that
provides high-performance disk mirroring. CallPilot uses RAID Level 1.
With Level 1 mirroring, two equal-capacity disk drives mirror one another.
One disk drive serves as the backup copy of the other disk drive. If one disk
drive fails, the other continues to run.
RAID configuring and splitting
Working with RAID involves the following:
•
Verifying the RAID firmware version
•
Upgrading or downgrading the RAID firmware
•
Configuring RAID using the LSI Elite 1600 controller and the Ctrl+M
menu at server boot-up
