88 Chapter 8 Replacing basic chassis components
To replace the upper fan holder foam
Step Action
1
Ensure that the fan cables are in the slots in the lower fan holder
foam.
2 Place the bottom end of the upper fan holder foam beneath the edge
of the server chassis.
3
Align the slots on the underside of the foam with the fans and add-in
boards.
Use your fingers on the underside of the upper fan holder foam to
determine correct placement of the fans. The fans must sit straight
inside the foam sockets. They must not align with the left side of
the foam.
4
Press the foam into place.
You may need to wiggle the fans so that the upper fan holder foam
sits flush with the bottom fan holder foam.
5
Ensure that the upper fan holder foam engages with the lip on the
media drives cage and is securely seated.
—End—
Replacing the side cover
After you complete your work with the interior components of the server,
replace the side cover. If you removed them, reinstall the chassis feet on the
bottom of the server.
To replace the side cover
CAUTION
Before you replace the side cover, ensure that no tools or loose
parts are inside the server chassis.
CAUTION
Use an ESD wrist strap to protect static-sensitive components.
