Appendix A
703t description reference
In this appendix
"Server features" (page 167)
"Slot assignments" (page 172)
"IRQ mapping table" (page 173)
Server features
This section provides a general overview of the 703t server.
Server dimensions
Height chassis only: 420 mm (16.75 in.)
with chassis feet: 440 mm (17.5 in.)
Width chassis only: 215 mm (8.6 in.)
with chassis feet: 320 mm (12.7 in.)
Depth (distance from front to back) 650 mm (26 in.)
Clearance
•
front: 250 mm (10 in.)
•
rear: 125 mm (5 in.)
•
side: 75 mm (3 in.)
Note: Additional side clearance is
required for service.
•
top: 75 mm (3 in.)
Weight of fully loaded system with
•
two SCSI hard drives
•
six populated boards
approximately 22 kg (46 lb)
