128 Chapter 10 RAID operations
11
Point to the c:\raidup\Win2k3 folder.
12
The system asks you to reboot.
Result: The system reboots to Windows 2003.
13
Check the driver, firmware and Power Console configuration.
a. Open the MegaRAID Power Console from the Start → Programs
menu.
b. Select Help About from the menu and verify the MegaRAID
Power Console version is 5.00i.
c. Select Adapter → Properties and verify the firmware version is
1L37 and the board type is LSI320-2.
d. Exit the Power Console.
14
Right click on C:\WINNT\SYSTEM32\DRIVERS\mraid3xx.sys and
select Properties → Version. Verify the Driver version is 6.45.
—End—
Verifying consistency on the drives
This optional consistency check on the logical drive of the RAID system
ensures that the data on the drives is identical. If any errors are found, they
are corrected automatically. Perform a consistency check before you split
the RAID system pack. A good data backup on an offline drive is important
if you need to revert to the CallPilot system from an unsuccessful upgrade
or update. The consistency check can take up to 2 hours to complete.
To perform a consistency check
Step Action
1
In Windows, click Start → Programs → Power Console Plus →
Launch Client.
Result: The MegaRAID Power Console Plus- Server Selection
window appears.
2
Ensure that Access Mode → Full Access is selected, and click OK.
Result: The MegaRAID Power Console Plus window appears
displaying the Logical View of the Physical Devices and the Logical
Devices. The status bar at the bottom of the window indicates that
RAID channels are being scanned. When scanning is done, the
screen refreshes and displays the Physical and Logical Devices.
Nortel CallPilot
703t Server Maintenance and Diagnostics
NN44200-702 01.03 Standard
5.0 3 April 2007
Copyright © 2007, Nortel Networks Nortel Networks Confidential
.
