172 Appendix A 703t description reference
Environmental condition
Specification
Operating shock No errors with a half sine wave shock
of 2G (with 1 millisecond duration)
Handling drop Operational after a free fall from 450
mm to 600 mm (18 in. to 24 in.)
(depending on weight)
Slot assignments
The slot assignment tables show:
•
the physical location of boards inside the server, relative to other boards
•
the order in which boards are installed (for example, board #1, 2, 3,
and so on)
•
how the boards are represented in CallPilot Manager applications (that
is, on the Maintenance Administration page)
•
the maximum capacity for each switch connectivity
Note: Your server may vary depending on what was ordered from
Nortel; therefore, your server may not have all of the slots populated.
Slot definition and numbering
In "Slot definition and numbering" (page 172), the term "slot" refers to the
available slot openings in the chassis, not the PCI connectors inside the
server.
The slots are numbered from the bottom of the server to the top. Slot 1 is
the bottom slot in the chassis when the chassis is standing upright.
Slot definition and numbering
Slot number
CallPilot-assigned
board label
a
Meridian 1 or
Communication Server
1000
PCI slot 7
(full length)
Not used Not used
PCI slot 6
(full length)
BRD06 RAID card
PCI slot 5
(full length)
BRD05 Not used
PCI slot 4
(full length)
BRD04 MPB96 board
a. In CallPilot Manager applications, the Callpilot-assigned board label may
appear. This label corresponds to the slot umber. For example, BRD01 refers
the board in slot 1.
Nortel CallPilot
703t Server Maintenance and Diagnostics
NN44200-702 01.03 Standard
5.0 3 April 2007
