146 Chapter 12 Working with DIMMs and the CPU
WARNING
Failure to follow the procedures in "Preparing the server
for hardware maintenance" (page 81) can result in
electrical shock or equipment damage.
2
Hold the DIMM only by its edges when you remove it from its
antistatic package.
3
Compare the length of the gold-edge connectors on the DIMM with
the socket, and align them accordingly.
4
Press the DIMM firmly down until it clicks into place inside the socket.
CAUTION
Use extreme care when installing a DIMM. Too much
pressure can damage the socket. DIMMs are keyed and
can be inserted in only one way.
Result: The plastic ejector levers close automatically indicating
correct installation.
—End—
Replacing the CPU
The 703t server motherboard provides two connectors for Xeon processor
chips, but only one is populated for CallPilot. For a single-CPU configuration,
the CPU must be installed on the CPU1 connector. A processor terminator
board is not required.
CPU replacement package contents
The CPU assembly package contains the following:
•
2.0 GHz AT 400 MHz FSB microprocessor with 512 kbytes of L2 cache
memory
Note: A higher frequency microprocessor may be provided if the
above mentioned frequency becomes obsolete.
• heat sink with guides and clips
•
syringe containing heat sink grease
•
heat sink housing
•
fan
Nortel CallPilot
703t Server Maintenance and Diagnostics
NN44200-702 01.03 Standard
5.0 3 April 2007
Copyright © 2007, Nortel Networks Nortel Networks Confidential
.
