Replacing or adding baseboard DIMMs 145
For instructions, see "Preparing the server for hardware
maintenance" (page 81).
WARNING
Failure to follow the procedures in "Preparing the server
for hardware maintenance" (page 81) can result in
electrical shock or equipment damage.
2
Gently push the plastic ejector levers of the DIMM socket out and
down to eject a DIMM from its socket.
CAUTION
Use extreme care when removing a DIMM. Too much
pressure can damage the socket slot. Apply only enough
pressure on the plastic ejector levers to release the DIMM.
3
Hold the DIMM only by its edges; be careful not to touch its
components or gold-edge connectors. Carefully lift it away from the
socket, and store it in an antistatic package.
4
Repeat to remove other DIMMs as necessary.
5
If you are replacing a DIMM, continue with "To install baseboard
DIMMs" (page 145).
—End—
To install baseboard DIMMs
CAUTION
Use only Nor tel-supplied DIMMs. A mixture of dissimilar metals
(from the use of other DIMMs) can cause later memory failures,
resulting in data corruption.
Step Action
1
Prepare the server for DIMM installation as described in "Preparing
the server for hardware maintenance" (page 81).
