RAID splitting 129
3
In the Logical Devices section, right-click the logical drive, and then
choose Check Consistency from the pop-up menu.
Result: The Check Consistency status dialog appears.
Note: The check can take up to 2 hours to complete. You are
informed when it is finished. If any errors are found, a window
with an error message is displayed.
4
Select Configuration → Exit to close the MegaRAID console.
Result: An end of session message appears.
5
Click OK.
—End—
RAID splitting
Ensure that your system is in full working order and the RAID hardware
configuration is set up properly as described on "Configuring RAID using
LSI Elite 1600 controller and Ctrl+M" (page 124).
ATTENTION
The most important thing to verify is that the RAID channel 1 is connected to the
first hard dr ive (top as facing the machine) and channel 2 is connected to the
second drive (bottom). Do that by either opening the lid and following the cables
or by removing one hard drive and observing which drive is marked dead by the
system. If the drive matches the graphic location on the Windows MegaRAID
console, proceed with the next step.
Full data backup
ATTENTION
As an extra precaution, Nortel recommends that a full system backup be
performed PRIOR to performing a RAID-split. For more information on system
backups, refer to the CallPilot Manager online Help.
To split the RAID
ATTENTION
Because the 703t has only one physical drive per channel, the RAID splitting
can be done using the Windows MegaRAID console without risk of CallPilot
database corruption.
Nortel CallPilot
703t Server Maintenance and Diagnostics
NN44200-702 01.03 Standard
5.0 3 April 2007
Copyright © 2007, Nortel Networks Nortel Networks Confidential
.
