137
Chapter 11
Replacing or adding voice processing
boards
In thischapter
"DSP numbering and location" (page 137)
"Replacing MPB96 boards" (page 138)
DSP numbering and location
DSPs are the built-in voice processing components on MPB boards. DSPs
are numbered to distinguish them in CallPilot maintenance programs, such
as the Maintenance page in CallPilot Manager. Each DSP supports up to
eight multimedia channels.
DSP numbering on MPB96 boards
The MPB96 board has 12 embedded DSPs. If an embedded DSP is faulty,
you must replace the entire MPB96 board.
Nortel CallPilot
703t Server Maintenance and Diagnostics
NN44200-702 01.03 Standard
5.0 3 April 2007
Copyright © 2007, Nortel Networks Nortel Networks Confidential
.
