Replacing the CD-ROM drive 113
Tighten the screws firmly.
7
Refer to the "Cabling diagram" (page 101), and then connect the
tape drive’s SCSI cable as follows:
a. Connect one end of the SCSI cable to LVD (the wide SCSI
controller of the server) on the server’s motherboard.
b. If a terminator is not attached to the cable, attach a wide SCSI
terminator to the other end of the SCSI cable.
c. Connect the second connector on the SCSI cable to the tape
drive.
d. For proper cooling and air flow, neatly fold and secure the excess
signal cable into the last bay (at the bottom of the server) so that
the cable does not drape across the baseboard or add-in boards.
CAUTION
Ensure that any cables in the proximity of the fans are
kept away from the fans. If a cable is caught in a fan,
the fan will break.
8
Connect the power cable of the tape drive.
Result: The tape drive is installed.
9
Replace the upper fan holder foam.
For instructions on replacing the upper fan holder foam, see "To
replace the upper fan holder foam" (page 88).
10
Replace the side cover.
11
Reconnect the peripheral device and power cables.
12
Power up the server.
13 Test the tape dr ive.
—End—
Replacing the CD-ROM drive
The CD-ROM drive is preinstalled at the factory. However, if it becomes
faulty, follow the procedure in this section to replace it.
