112 Chapter 9 Replacing media drives
WARNING
Failure to follow the procedures in "Preparing the server
for hardware maintenance" (page 81) can result in
electrical shock or equipment damage.
2
Disconnect the power and signal (SCSI) cables of the faulty drive.
3
Open the front panel on the server.
4 Remove and save the two screws that secure the tape drive to the
front of the chassis.
5
Pull the tape drive out of the chassis, and then place it on an
antistatic surface.
Note: If you plan to leave the bay empty, install a filler panel and
stainless steel EMI shield on the bay.
6
Remove the four screws and two slide rails from the tape drive.
7
Place the drive in an antistatic protective wrapper.
8
Continue with ""To install a replacement tape drive" (page 112)"
below.
—End—
To install a replacement tape drive
Step Action
1
Remove the new tape drive from its protective wrapper, and place it
on an antistatic surface.
2
Record the drive model and serial numbers in your equipment log.
3
Set the settings of the tape drive as described in "Tape drive
configuration" (page 110).
For instructions on changing the tape drive’s settings, refer to the
drive manufacturer’s documentation.
4
Attach the slide rails to the replacement tape drive with the screws
you removed earlier.
5
Slide the tape drive into the tape drive bay.
6
Secure the tape drive to the front of the server with the screws you
removed earlier.
Nortel CallPilot
703t Server Maintenance and Diagnostics
NN44200-702 01.03 Standard
5.0 3 April 2007
Copyright © 2007, Nortel Networks Nortel Networks Confidential
.
