Replacing the tape drive 111
Tape drive installation overview
To remove the tape drive
CAUTION
Use an ESD wrist strap to protect static-sensitive components.
Note: The tape drive is installed in the second bay from the top.
Step Action
1
Prepare the server for tape drive replacement as follows:
a. Shut down the server, and then disconnect the power and
peripheral device cables.
b. Remove the side cover.
c. Remove the upper fan holder foam.
For instructions, see "Preparing the server for hardware
maintenance" (page 81).
Nortel CallPilot
703t Server Maintenance and Diagnostics
NN44200-702 01.03 Standard
5.0 3 April 2007
Copyright © 2007, Nortel Networks Nortel Networks Confidential
.
