110 Chapter 9 Replacing media drives
Filler panels and EMI shields
System EMI integrity and cooling are both protected by drives installed
in the bays or by filler panels and EMI shields covering the bays. When
installing drives, save the panel and shield to reinstall later, in case you
remove the drive and do not reinstall one in the same bay.
Tape drive configuration
Note: Some settings may already be properly configured. If it is not
clear from the drive manufacturer’s documentation how to set jumpers,
contact your Nortel technical support representative.
Ensure that the hard drives are configured as follows (for instructions, refer
to the original equipment manufacturer documentation):
•
SCSI ID: 2
•
active terminators (Term Enable): disabled
Note: Termination is provided by an Active SCSI terminator that
you connect to the end of the SCSI cable (see "SCSI and IDE dr ive
cabling" (page 101)).
•
parity checking: enabled
•
termination power (TPWR): enabled
•
all other settings: factory default
Nortel CallPilot
703t Server Maintenance and Diagnostics
NN44200-702 01.03 Standard
5.0 3 April 2007
Copyright © 2007, Nortel Networks Nortel Networks Confidential
.
