86 Chapter 8 Replacing basic chassis components
CAUTION
Use an ESD wrist strap to protect static-sensitive
components.
2
Place your fingertips in the depression on the side cover, and then,
as you apply pressure, pull the cover approximately 2.5 cm (1 in.)
away from the front of the server until it stops.
3
Use both hands to lift the cover away from the chassis.
4
Set the cover aside.
—End—
Removing and replacing the upper fan holder foam
The interior of the server contains two layers of fan holder foam, which
secure and stabilize the cooling fans and add-in boards. The fan holder
foam also maintains the space that is required between the boards for
cooling. You may be required to remove the upper fan holder foam to access
and work with some components.
Nortel CallPilot
703t Server Maintenance and Diagnostics
NN44200-702 01.03 Standard
5.0 3 April 2007
Copyright © 2007, Nortel Networks Nortel Networks Confidential
.
