134 Chapter 10 RAID operations
What to do How to do it
4. In the Configure menu, select New Configuration. Press Yes to proceed.
The system should display both SCSI channels, each having one drive.
SCSI ID’s should be 0 for each channel. All disk drives should be in
READY state.
Note: Do not use the Load command on the Configure menu. This command
is not for RAID operations.
5. Create the first logical drive by selecting Channel-1 ID 0 (A01-01), and
pressing the Spacebar. The display will change to ONLIN A01-01. Select
Channel-2 ID-0 (A01-02) and again press the Spacebar. After selection,
the drives will blink, press Enter or F10 to create first logical drive.
6. Press the Space bar to Select Configuration Array.
Span-1 appears in the
box opened for the A01 logical drive.
7. Configure the logical drives by pressing F10. The system prompts for
each of the logical drives to consecutively select
RAID 1;
Size: accept the size displayed;
Advanced Menu
Accept
SPAN = NO
Change the last value to NOSPAN if required.
Accept these new values by pressing Enter. The system will prompt you to
save the configuration. Highlight Yes and press Enter. Exit the submenu
by pressing Esc.
8. In the main menu enter the Initialize submenu. Select the logical drive by
pressing F2. Press F10 and consecutively select YES to initialize the drive
pack. When done, press any key to return to the main menu.
9. Exit the utility by pressing Esc. Save the configuration when prompted.
Press Ctrl+Alt+Delete as indicated by the menu to reboot.
Task summary for RAID splitting
Note: This summary should be used only after reviewing the more
detailed procedures and warnings in this chapter.
What to do How to do it
Ensure that
your system
is fully working
and the RAID
hardware
is properly
configured.
The most important thing to verify is that the RAID channel 1 is connected to
the first hard drive (top as facing the machine) and channel 2 is connected
to the second drive (bottom). Open the lid and follow the cables or remove
one hard drive and observe which drive is marked dead by the system. If
the drive matches the graphic location on the Windows MegaRAID console,
proceed with the next step.
