81
Chapter 8
Replacing basic chassis components
In this chapter
"Preparing the server for hardware maintenance" (page 81)
"Removing the side cover" (page 84)
"Removing and replacing the upper fan holder foam" (page 86)
"Replacing the side cover" (page 88)
"Cooling fans description" (page 89)
"Replacing a front system fan" (page 92)
"Replacing a rear system fan" (page 95)
"Replacing the processor fan" (page 98)
Preparing the server for hardware maintenance
DANGER
Before you begin working inside the server, do the following:
1. Power off and disconnect all peripheral devices that are
connected to the CallPilot server.
2. Power off the server and disconnect the power cord.
For more information, see "Preparing the server for
hardware maintenance" (page 81).
Nortel CallPilot
703t Server Maintenance and Diagnostics
NN44200-702 01.03 Standard
5.0 3 April 2007
Copyright © 2007, Nortel Networks Nortel Networks Confidential
.
