120 Chapter 9 Replacing media drives
Slide the assembly toward the front of the system, and engage it with
the bracket tabs on the side of the drive bay.
Note: The bottom of the drive/bracket assembly must accept the
tab that sticks out from the inside of the front panel. Ensure that
the front of the drive fits flush in the front opening of the system.
(See the "Floppy disk drive installation overview" (page 117).)
6
Secure the assembly to the server’s front panel with the screws you
removed earlier. Tighten the screws firmly.
7
Connect the floppy disk drive’s signal cable to the drive.
Note: The connectors are usually keyed to allow you to easily
reconnect them to the drive. If they are not keyed, insert both
cables so that the red wires are closest to the center of the drive.
CAUTION
If the floppy disk drive contains a floppy disk and the
signal cable is connected backwards, data loss can occur.
The LED at the front of the drive will also remain lit after
the server is powered up.
8
Connect the power cable of the floppy disk drive to the drive.
Result: The floppy disk drive is installed.
9 Replace the upper fan holder foam.
For instructions on replacing the upper fan holder foam, see "To
replace the upper fan holder foam" (page 88).
10
Replace the side cover.
11
Reconnect the peripheral device and power cables.
12
Power up the server.
13
Test the floppy disk drive.
—End—
