Configuring RAID using LSI Elite 1600 controller and Ctrl+M 125
8
From the Management menu select Objects → Adapter, then ensure
the Adapter 1 values are set as follows:
Flex RAID Power Fail: Enabled
Fast Initialization: On
Disk Spin up Timing: 1 Disk every 6 secs
Cache Flush Timings: Every 4 seconds
Rebuild Rate: 30%
Alarm Control: Enabled
Other Adapter Options:
•
Emulation: Mass Storage
•
Auto Rebuild: Disabled
•
Initiator ID: 7
•
Cluster Mode: Disabled
•
Multiple PCI Delayed Transactions: Disabled
• Force Boot: Off
•
Coercion Algorithm: GigaByte Way
•
Cc Restoration: Enabled
Note: The Coercion Algorithm must be set properly. Once
changed, it cannot be changed again. The only way to reset
it is to reconfigure RAID from scratch and load the default
configuration, then reboot.
9
Select Objects → Channel and press Enter.
10 From the Channel menu, ensure the values are set as follows:
Ter mination State: Enabled
SCSI Transfer Rate: 160M
11
Select Configure menu → New Configuration. Click Yes to proceed.
Result: The system should display both SCSI channels, each
having one drive. SCSI IDs should be 0 for each channel. All disk
drives should be in READY state.
Note: Do not use the Load command on the Configure menu.
This command is not for RAID operations.
12 Create the first logical drive by selecting Channel-1 ID 0 (A01-01),
and pressing the Spacebar. The display will change to ONLIN
A01-01. Select Channel-2 ID-0 (A01-02) and again press the
Spacebar.
Result: After selection, the drives will blink.
Nortel CallPilot
703t Server Maintenance and Diagnostics
NN44200-702 01.03 Standard
5.0 3 April 2007
Copyright © 2007, Nortel Networks Nortel Networks Confidential
.
