Interpreting front panel LEDs 21
Tape drive LED states
The 703t server is equipped with an SLR60 tape drive. Three LEDs are
located on the drive’s front panel. They are referred to as left, center, and
right in the following table:
SLR60 LEDs
Left -
Ready
Green
Center -
Activity
Green
Right -
Error
Amber Description
On On On
•
LED test (2 seconds at power on) is
running.
Blinking Off Off
•
Power-up self-test is running.
•
Diagnostic cartridge activity is running.
Off Off Off
•
Cartridge is not inserted
•
Tape is not loaded
On Off Off
•
Cartridge is not inserted
• Tape is loaded but is not moving
On Blinking Off
• Tape is loaded and moving
•
Tape is loading or unloading
•
Cartridge is ejecting
Off Off On
•
Cleaning is required
•
Cartridge/tape is not loaded
On Off On
•
Cleaning is required
• Tape is loaded but not moving
On Blinking On
• Cleaning is required
•
Tape is loaded and moving
•
Tape is loading or unloading
•
Cartridge is ejecting
Note: If the LED states indicate an error, contact your Nortel technical support
representative.
Nortel CallPilot
703t Server Maintenance and Diagnostics
NN44200-702 01.03 Standard
5.0 3 April 2007
Copyright © 2007, Nortel Networks Nortel Networks Confidential
.
