8 Contents
Running integrated diagnostics 64
Viewing the last diagnostic results 66
Working with the Multimedia Monitor 67
Working with the Channel Monitor 69
Chapter 7 Using CallPilot system utilities 73
Overview 73
Diagnostics Tool 74
PEP Maintenance utility 75
Session Trace 75
System Monitor 77
Chapter 8 Replacing basic chassis components 81
Preparing the server for hardware maintenance 81
Removing the side cover 84
Removing and replacing the upper fan holder foam 86
Replacing the side cover 88
Cooling fans description 89
Replacing a front system fan 92
Replacing a rear system fan 95
Replacing the processor fan 98
Chapter 9 Replacing media drives 101
SCSI and IDE drive cabling 101
Replacing a faulty hard drive 102
Replacing the tape drive 109
Replacing the CD-ROM dr ive 113
Replacing the floppy disk drive 116
Chapter 10 RAID operations 121
RAID overview 121
Verifying the RAID firmware 122
Configuring RAID using LSI Elite 1600 controller and Ctrl+M 124
Replacing the LSI1600 card with LSI320-2 126
Verifying consistency on the dr ives 128
RAID splitting 129
Task summary for configuring RAID 133
Task summary for RAID splitting 134
Chapter 11 Replacing or adding voice processing boards 137
DSP numbering and location 137
Replacing MPB96 boards 138
Chapter 12 Working with DIMMs and the CPU 143
Replacing or adding baseboard DIMMs 143
Replacing the CPU 146
Nortel CallPilot
703t Server Maintenance and Diagnostics
NN44200-702 01.03 Standard
5.0 3 April 2007
Copyright © 2007, Nortel Networks Nortel Networks Confidential
.
