5.9.1.1 Removing toner feed
A29246-X20-X-4-7680 / fa509.fm 141
7. Remove the hose from the developer
station and the air intake.
8. Remove the pin-and-socket connector
between the drain head and the toner
bottle holder.
9. Press back on the drain head
mounting release and remove the
drain head from the mounting.
10. 5.9.1.2 Installing toner feed >>> page 142
Proceed as follows:
