4 Operator panel
A29246-X20-X-4-7680 / fa400.fm 59
4 Operator panel
4.1 Overview
This section describes the individual areas of the operator panel with the most important
icons and buttons. You will also find out how to navigate through the menus, set
parameters, and start and end the replacement of consumables and expendables.
You will find information on the following topics:
4.2 Operator panel description >>> page 60
4.3 Using the operator panel >>> page 80
Note
Detailed information on all menus and operating elements is also available directly in
the operator panel via the context-sensitive Direct Help. The context-sensitive Direct
Help can be called up by selecting the relevant menu or operating element and then
pressing the F1 key.
If necessary, all the requirements for setting the respective parameters are also listed
in the context-sensitive Direct Help. Specified standard settings and values are
denoted in bold.
