Oce VarioStream 7000 SINGLE - Page 214

6.10 Cleaning the toner suction system
214 A29246-X20-X-4-7680 / fa605.fm
4. Move the lever upwards to swivel off
the drain head.
5. Remove the toner bottle from the
container.
6. Open cover.
Proceed as follows:
2 of 5
