7.2.4 Replacing the developer
250 A29246-X20-X-4-7680 / fa701.fm
20. Remove the tube end from the
developer opening and remove the
funnel from the developer bottle.
21. Swivel on the fan to the developer
station and turn the turning knob to the
right.
22. Close the left and center door at the back of the printing system.
23. Click the following button on the operator panel to complete refilling the developer:
All printing system assemblies are checked (duration approx. 2-3 minutes) before the
printing system is switched to the "Ready" status.
In both cases, the message on the operator panel is automatically deleted, the
replacement of the developer is recorded in the <Consumables history> menu and
the consumable counter is reset.
Proceed as follows:
