7.3.1 Replacing the photoconductor drum
262 A29246-X20-X-4-7680 / fa701.fm
5. Attach clamping screw and secure tightly.
6. Swivel on the door in front of the photoconductor drum and close the lever.
7. Close both doors and the cover at the front of the printing system.
8. Select the type of the inserted photoconductor drum ("DRUM TYPE:") .
9. Select inserted photoconductor drum ("DRUM").
10. Enter on the operator panel whether a new photoconductor drum has been inserted:
•
The message on the operator panel is deleted automatically, the replacement of
the photoconductor drum is recorded in the <Consumables history> menu and the
consumable counter is reset.
•
If the PC drum is not replaced but only cleaned, for example,
the process is documented in the <Consumables history> menu.
Status display in the Consumables history:
11. Click the following button on the operator panel to complete PC drum replacement:
All printing system assemblies are checked (duration approx. 2-3 minutes) before
the printing system is switched to the "Ready" status.
In both cases, the message on the operator panel is automatically deleted, and the
replacement of the photoconductor drum is recorded in the <Consumables history>
menu.
Caution
The old photoconductor drum must be disposed of as hazardous waste.
Store the old drum and any flakes of coating in the original carton, and keep ready
for collection by service or the contracted shipping company.
12. Have the old photoconductor drum ready for collection by
the service center or the
contracted shipping company(see section 2.6.7 Disposal, page 36).
Proceed as follows:
