7.3.3 Replacing the cleaning brush
266 A29246-X20-X-4-7680 / fa701.fm
8. Loosen both knurled screws of the
brush cover cap.
9. Slowly remove cover cap with the
cleaning brush sitting on the insert
taper and put to the side.
10. If the insert taper is not secured,
remove the cleaning brush by hand.
Proceed as follows:
