7.3.4.2 Replacing the transfer corotron (1 cartridge) (pinfed)
272 A29246-X20-X-4-7680 / fa702_pinfed.fm
3. Swivel up the locking lever and
release.
4. Swivel down the paper transporter by
the handle to the stop point.
5. When doing so, ensure that the locking
lever is engaged on the conveyor.
Proceed as follows:
