7.3.9 Replacing the pressure roller
324 A29246-X20-X-4-7680 / fa703.fm
5. Close the cover underneath the fuser
station.
6. Swivel in waste collector and lock with
the pressure pin.
7. Swivel on oiling unit and turn the oiling
unit turning knob to the right.
8. Close side door of fuser station.
9.
Raise the stacker top by pressing the left key under this icon .
Proceed as follows:
2 of 3
