7.3.10 Replacing the waste collector
A29246-X20-X-4-7680 / fa703.fm 329
2. Swivel in waste collector and lock with
the pressure pin.
3. Swivel on oiling unit and turn the oiling
unit turning knob to the right.
4. Close side door of fuser station.
5. Click on the following button:
Proceed as follows:
2 of 2
